Ladder lockout devices restrict access to a ladder so it cannot be climbed until an authorised worker removes the lock. E-Square manufactures six distinct families of ladder lockout covers, suitable for portable stepladders through to fixed vertical ladders: single-sided and double-sided flexible PVC covers, velcro flexible PVC covers, strap-and-grommet flexible PVC covers, rigid steel covers in multiple configurations including fall-arrest-compatible variants, and adjustable two-plate steel lockouts for flat-rung and round-rung ladders. Supplied across industries in 109 countries.
Browse Complete Product Line Below
Showing 1–8 of 24 results
-
Single Sided Ladder Lockout – 1 (32″ x 13″)
ES-LL-SS-1
-
Single Sided Ladder Lockout – Large 2 (42″ x 15″)
ES-LL-SS-2
-
Single Sided Ladder Lockout Small – 1 (32″ x 13″) with Kit
ES-LL-SS-1K
-
Single Sided Ladder Lockout Large – 2 (42″ x 15″) with Kit
ES-LL-SS-2K
-
Double Sided Ladder Lockout – 1 (70″ x 13″)
ES-LL-DS-1
-
Double Sided Ladder Lockout Large – 2 (87″ x 15″)
ES-LL-DS-2
-
Double Sided Ladder Lockout Small – 1 (70″ x 13″) with Kit
ES-LL-DS-1K
-
Double Sided Ladder Lockout Large – 2 (87″ x 15″) with Kit
ES-LL-DS-2K
Our New Catalogue
Discover the widest range of lockout tagout products available globally.
Enter your email below and get a link to download your digital copy.
What is a Ladder Lockout Device?
Ladder lockout is an access isolation device that covers the climbing portion (accessible lower rungs) of a ladder, so it cannot be used until an authorised worker removes the lockout. It is the primary access control for ladders that are damaged, under inspection, located in restricted areas, or temporarily out of service.
Consider the ladders on your site right now:
The Monkey ladders on your reactor or vessel – climbed without isolation.
The fixed ladder on your silo or tank – accessed while agitators run below.
The ladder on your tanker – stepped on while the pump is live.
Oil & gas, pharma, FMCG, cement, steel – manufacturing facilities know this risk.
Picture a technician at a processing facility climbing a mixing vessel ladder for a routine check. The agitator below is not isolated. A colleague restarts it remotely.
Work at Height. Slip, Trip & Fall. Ladder Safety. Lockout Tagout.
All four hazards. One Ladder. One moment – Ladder Lockout Device is the single intervention that addresses all four, physically and permanently.
Choosing the right mechanism depends on the ladder type and the protection level required. A flexible PVC cover wraps over the rungs of stepladders, extension ladders or fixed vertical ladders and is locked using brass eyelets with a cable lockout and padlock, a strap-and-grommet system secured with a padlock, or velcro straps at top and bottom. A rigid steel cover hangs on the ladder via adjustable top hooks and is secured with a long-shackle padlock through an integrated hasp; it is available in standard, angular, wings, half-cover, top-mounted, top-mounted full cover, A-section, fixed-hinged, hump, and hump-and-wings variants. The hump variants integrate with rope-based or aluminium-channel personal fall arrest systems. An adjustable two-plate steel lockout covers the first few rungs with a heavy-duty blocking plate while a sliding base plate grips the lower rungs from below for added stability, and supports group lockout where multiple workers each apply their own padlock.
E-Square: Ladder Lockout Device Manufacturer & Supplier
E-Square Alliance is India’s largest lockout tagout manufacturer, with over 1,800 LOTO SKUs designed and produced in-house at our New Delhi facility. Our ladder lockout range is the widest available from a single manufacturer: single-sided and double-sided PVC covers, Velcro and strap-and-grommet covers, a complete steel ladder lockout range across standard, hump, wings, half-cover, A-section, fixed-hinged and top-mounted configurations, plus adjustable two-plate steel lockouts for flat and round-rung ladders. These are built on proprietary tooling backed by 72+ design patents.
We hold Star Export House status from DGFT and ship direct to industrial buyers, distributors and resellers across 109+ countries. As an OEM supplier to major international industrial brands, our products meet the quality and compliance bar set by global procurement teams; a standard we have maintained over two decades. Every ladder lockout is engineered for real-world site conditions: material choices spanning flexible woven PVC, powder-coated steel, aluminium and stainless steel; with integrated padlock hasps or cable-lock kits matched to the design. Our high-visibility colours are backed by OSHA-style danger signages in multiple languages.
Our Range of Ladder Lockout Devices
We manufacture six ladder-lockout families to match the ladder type, the access-control requirement and the environment. Browse the subcategories below for exact specifications, dimensions and model codes.
| Family | Fits / Material | How it secures the ladder | Sizes / SKUs |
Single Sided Ladder Lockout | Stepladders, extension ladders and other climbing apparatus; flexible woven PVC | Cover is placed over 3-4 rungs on one side; brass eyelets at both ends; an EML cable lockout passes through the eyelets and is secured by a padlock. | ES-LL-SS-1 (32” × 13”), ES-LL-SS-2 (42” × 15”); Kit versions include cable lockout, padlock and 5 tags. |
Double Sided Ladder Lockout | Stepladders and other climbing apparatus where both faces need to be covered; weather-resistant flexible woven PVC | Cover wraps over the front and back of 3-4 rungs; brass eyelets at both ends; secured at the bottom with a padlock through the two eyelets. | ES-LL-DS-1 (70” × 13”), ES-LL-DS-2 (87” × 15”); Kit versions include cable lockout, padlock and 5 tags. |
Velcro Ladder Lockout | Standard ladders requiring a quick-fit deterrent; weather-resistant flexible woven PVC | Hook-and-loop (Velcro) fastening at the top and bottom secures the cover to the ladder rungs; acts as a visual safety deterrent | ES-LL-V (64” × 13”); colour: safety yellow |
Flexible PVC Ladder Lockout (Strap & Grommet) | Fixed vertical ladders, extension ladders and stepladders; heavy-duty woven PVC | Cover is placed over the rungs; rear strap passes through a D-ring at the bottom; the strap’s reinforced locking holes align and are secured with a padlock. | ES-LL-F-PVC (120” × 15”); designed to support OSHA 1926.1053(b)(8) |
Steel Ladder Lockout | Fixed vertical, A-section and other industrial ladders; powder-coated steel, aluminium or stainless steel. | Rigid panel hangs on the ladder via 2 top hooks with adjustable lower hook for stability; integrated padlock hasp accepts the long-shackle padlock. Available top-mounted, hinged, A-section, with side wings, half cover, full cover and hump variants for fall-arrest systems | ES-LL-ST-1/2 (Standard 62” x 13/15), ES-LL-ST-A (Angular), ES-LL-ST-W (Wings), ES-LL-ST-HC (Half Cover), ES-LL-ST-TM (Top Mounted), ES-LL-ST-AS (A-Section), ES-LL-FHL (Fixed, Hinged & Lockable), ES-LL-TMFC (Top Mounted Full Cover), ES-LL-ST-HUMP, ES-LL-ST-H&W (Hump + Wings), plus top-mounted flexible ES-LL-TM-F |
Adjustable Steel Ladder Lockout | Flat-rung and round-rung industrial ladders; powder-coated steel | Heavy-duty blocking plate covers the first few rungs; a second base plate slides in from behind, gripping the lower rungs from below; adjustable plate height fits different rung spacings; multiple padlock points support group lockout. | ES-LL-ST-ADJ-FR (Flat Rung, red, 18”×15”×3.7”, 4 kg), ES-LL-ST-ADJ-RR (Round Rung, yellow, 18”×15”×1.8”, 4 kg); signs available in 6 languages (EN, ES, FR, DE, AR, HI) |
Standardising ladder access control across a site or estate? We supply the full ladder-lockout range in volume, with custom sizing, materials and multi-language signages.
How to Choose the Right Ladder Lockout
Selecting the correct device comes down to five practical questions:
What type of ladder is it? Match the device to the ladder. Stepladders and extension ladders suit the flexible PVC covers (single sided, double sided or Velcro). Fixed vertical ladders are best served by the strap-and-grommet PVC, the steel range or the adjustable two-plate lockouts. A-section ladders take the dedicated ES-LL-ST-AS.
What level of security do you need? Velcro is a quick-fit visual deterrent without a padlock. The PVC, strap-and-grommet, steel and adjustable lockouts all accept a padlock and support lockable access control. For full restricted access, the steel and adjustable ranges with integrated padlock hasps offer the most robust protection.
Flat or round rungs? For adjustable two-plate lockouts on industrial ladders, ES-LL-ST-ADJ-FR fits flat rungs and ES-LL-ST-ADJ-RR fits round rungs. Both adjust for different rung spacings and accept group-lockout padlocks.
Is fall-arrest integration needed? If the ladder is fitted with a rope-based or aluminium-channel personal fall arrest system, choose the Standard with Hump (ES-LL-ST-HUMP) or Hump and Wings (ES-LL-ST-H&W) variant, which allows secure placement without obstructing the fall-arrest line.
What’s the environment? Powder-coated steel or PVC is suitable for indoor / general use. Aluminium gives a lightweight, corrosion-resistant alternative. Stainless steel (smooth or heavy-duty texture) is built for marine, harsh-industrial and high-corrosion environments.
Not sure which device fits your ladders?
Benefits of E-Square Ladder Lockout Devices
Our ladder lockouts make access isolation reliable, visible and adaptable to almost any ladder design:
- Six families, one manufacturer: From flexible PVC covers to rigid steel and adjustable two-plate lockouts, sized to portable, fixed and A-section ladders.
- Group lockout supported: Multiple padlock points on the adjustable steel range let several authorised workers each apply their own padlock, with release only when all are removed.
- Fall-arrest compatible: The hump and hump-and-wings variants integrate with rope-based and aluminium-channel personal fall arrest systems on fixed vertical ladders.
- Multi-language safety signage: Standard signs supplied in English, Spanish, French, German, Arabic and Hindi, with bilingual and fully customised options.
- Material range for every environment: Powder-coated steel (yellow, grey, red, black), aluminium and stainless steel (smooth or heavy-duty texture).
- Customisation available: Colour coding, laser engraving, private labelling, company logos, location identifiers, QR codes, custom sizing, and signage in your language. Custom legends and branding are supplied free of charge.
Compliance & Standards
Our ladder lockout devices are designed to support compliance with OSHA 29 CFR 1926.1053(b)(8): the industry standard governing ladder safety. Once our ladder lockout devices are fitted and locked, the ladder remains inaccessible until the authorised worker removes the padlock.
For international operations, our ladder lockouts also support ladder safety programs aligned with:
- AS 1657:2018 (Australia: Fixed platforms, walkways, stairways and ladders: Design, construction and installation)
- AS/NZS 1892 (Australia / New Zealand: portable ladders)
- EN ISO 14122-4:2016 (Europe: Safety of machinery: Permanent means of access to machinery, Part 4: Fixed ladders)
- EN 131 (Europe: portable ladders, Parts 1–7; substantially revised January 2019)
- Directive 2009/104/EC (Europe: minimum safety and health requirements for the use of work equipment, incorporating Directive 2001/45/EC on temporary work at a height)
- CSA Z11-18 (R2022) (Canada: portable ladders)
Regulatory requirements vary by jurisdiction and industry. Always verify current requirements with your local authority or a qualified safety professional.
Ladder Lockouts for Every Industry
Ladders are essential for everyday operations across various industrial settings, and uncontrolled access to a damaged or restricted ladder can lead to falls from height. This is one of the most violated standards that causes workplace injury and death. Our ladder lockouts are used wherever ladders need to be kept out of service or under authorised access only.
Construction Power & Energy Oil & Gas Chemical Steel & Iron Heavy Industry
